Author : Marty Brown Publisher : Butterworth-Heinemann. ISBN : 978-0750673297 EAN : 673297
Dimensions (cm) : 25.4(H) x 17.7(W) x 1.5(T) Weight (kg) : 0.49
Added To Bookshop : 9/
2/
2008
Description
-- Second Edition
Guides engineers through a step-by-step design framework for a wide variety of power supplies, many of which can be designed in less than one day
Provides easy-to-understand information about often complicated topics, making power supply design a much more accessible and enjoyable process
A practical, "start-to-finish" design reference. It is organized to allow both seasoned and inexperienced engineers to quickly find and apply the information they need. Features of the new edition include updated information on the design of the output stages, selecting the controller IC, and other functions associated with power supplies, such as: switching power supply control, synchronization of the power supply to an external source, input low voltage inhibitors, loss of power signals, output voltage shut-down, major current loops, and paralleling filter capacitors. It also offers coverage of waveshaping techniques, major loss reduction techniques, snubbers, and quasi-resonant converters.
Contents:
Power System Organization, Power Supply Technology, Power Supply Design, Basic Linear Regulator Operation, Elementary Discrete Linear Regulator Designs, 3-Terminal Regulator Designs, Fundamentals of PWM Switching Power Supplies, Generalized Design Flow of Magnetic Elements, Rectification and Filtering, Synchronous Rectifiers, The Power MOSFET, Laying Out the Printed Circuit Board, PWM Switching Power Supply Design Examples, Fundamentals of Quasi-Resonant Operation, Uses of Resonant Techniques within Switching Power Supplies, Major Parasitic Influences within High Frequency Switching Power Supplies, Efficiency and EMI Performance of a Switching Power Supply (including traditional areas of significant loss, zero voltage and zero current transition switching techniques, Lossless passive snubbing, minimizing losses in the magnetics), and related Appendices
